Sweep High M

by davidphilipbarr

34 keys split, 2 halves

MX Pro Micro socket ZMK

No summary recorded.

Layouts

• 34 keys

Spec

Stars

— not recorded —

Key spacing

— not recorded —

Build method

PCB

Soldering

— not recorded —

SMD required

— not recorded —

Controller

Pro Micro socket

Body

split, 2 halves

Switch footprint

MX

Firmware

ZMK (cradio)

Key wiring

— not recorded —

Licensing

Hardware

Apache-2.0

Firmware

Apache-2.0

Documentation

Apache-2.0

Sources

• https://github.com/davidphilipbarr/sweep
