Choc LED Ergo Travel

by jpconstantineau

54 keys split, 2 halves, TRRS cable between halves

Choc v1 Pro Micro socket QMK

What fits this board →

No summary recorded.

Layouts

• 54 keys

Spec

Stars

— not recorded —

Key spacing

— not recorded —

Build method

PCB

Soldering

— not recorded —

SMD required

— not recorded —

Controller

Pro Micro socket

Body

split, 2 halves, TRRS cable between halves

Switch footprint

Choc v1

Firmware

QMK (ergotravel/rev1)

Firmware targets

— not recorded —

Key wiring

4×7 matrix, column-to-row diodes

Room for

— not recorded —

Licensing

Hardware

MIT

Firmware

MIT

Documentation

MIT

Sources

• https://github.com/jpconstantineau/ergotravel
