41 1350
41 keys unibody
Alps / Choc v1 Pro Micro socket QMK
What fits this board → Compare with another board →
Record 82% complete · 14 of 17 fields
- ✓ Layout
- ✓ Switch footprint
- ✓ Build method
- ✓ Controller
- ✓ Body
- ✓ Firmware
- ✓ Hardware license
- ✓ Firmware license
- ✓ Documentation license
- ✓ Key pitch
- ✓ Soldering
- ✗ Firmware targets
- ✓ Summary
- ✓ Key wiring
- ✓ Hotswap
- ✗ Splay
- ✗ Stagger
choc-v2 & v1 switches, MX-spaced, integrated/onboard nrf52840 controller
Layouts
- 41 keys
Spec
Shape
- Body
- unibody
- Splay
- — not recorded —
- Stagger
- — not recorded —
- Key spacing
- Choc spacing · 18 × 17 mm
Switches
- Switch footprint
- Alps, Choc v1
- Hotswap
- Kailh socket
Electronics
- Controller
- Pro Micro socket
- Connectivity
- Wireless with a nice!nano v2 — needs a ZMK config
- USB port
- USB-C or micro-USB, depends on the dev board
- Firmware
- QMK (b_sides/rev41lp)
- Firmware targets
- — not recorded —
- Key wiring
- 7×6 matrix, column-to-row diodes
- Room for
- — not recorded —
- Power switch
- yes
- Exposed components
- — not recorded —
Building it
- Build method
- PCB
- Soldering
- SMD, hand-solderable (IC, other)
- SMD required
- yes
Licensing
- Hardware
- MIT
- Firmware
- MIT
- Documentation
- MIT
